High Capacity Sand Dredger With Deep Water Dredging Ability Solid Capacity 600-700m3/H

Brand Name : yongsheng

Model Number : ys-20inch

Place of Origin : china

MOQ : 1

Price : 115000usd/piece

Payment Terms : T/T,L/C

Supply Ability : 100piece/Year

Delivery Time : 30 work days

Packaging Details : Container

Customized : customized

Condition : new

Warranty : 1 year

Water Flow : 3800m3/H

Solid Capacity : 600-700m3/H

Max.Dredging Depth 45° : 14m

Discharge Distance : 1500m

size : 26m*7.6m*2.0m

Main Engine : 1250kw

consumption : 240L/H

Application : sand suction

Work site : river lake sea canal

Auxiliary engine power : 456kw

Core Components : Engine, Pump

Contact Now

Sand Dredger with Deep Water Dredging Ability

1.Brief Introduction

jet suction sand dredger refers to a ship that uses the power of water to transport the silt (or fine sand, sea

sand, etc.) flushed by the water column sprayed by the high-pressure water gun to the destination through

a pipeline under the action of the sand suction pump. It has a novel design, simple operation, and high efficiency.

It is suitable for river dredging, lake and reservoir dredging, land reclamation, port terminal cleaning, sand

pumping, etc. The equipment consists of a hull, a dredging pump, a high-pressure water pump, a power unit,

a winch, etc.

High Capacity Sand Dredger With Deep Water Dredging Ability Solid Capacity 600-700m3/H

Product Paramenters:
Model
Soild
capacity
Water flow
Dredging depth
Discharge distance
Main engine
Auxiliary engine
Total consumption
size(m)
6inch
40-50
m3/h
250
m3/h
6M
500M
120
KW

18L/H
10*3.8*1.6
8inch
80-100
m3/h
500
m3/h
8M
500M
176
KW
60KW
40L/H
14*4.5*1.2
10inch
150-180
m3/h
900
m3/h
10M
800M
294
KW
88KW
60L/H
17*5*1.2
12inch
200-250
m3/h
1400
m3/h
10M
1000M
456
KW
110KW
80L/H
20*6*1.5
14inch
300-400
m3/h
2000
m3/h
12M
1500M
735
KW
120KW
120L/H
24*6.6*1.6
16inch
400-500
m3/h
2600
m3/h
14M
1500M
882
KW
258KW
150L/H
24*7.2*1.8
18inch
500-600
m3/h
3000
m3/h
14M
1500M
1103
KW
456KW
220L/H
24*7.6*2.0
20inch
600-700
m3/h
3800
m3/h
14M
1500M
1250
KW
456KW
240L/H
26*7.6*2.0
Note: Because this equipment is a customized product, the maximum conveying distance of one pump is 1000-2000m. If long-distance conveying is required, a separate relay pump group is added.
The above output is calculated based on the conventional flow rate 15-20% concentration. If the long-distance conveying concentration will be reduced, it can be calculated based on about 15% of the flow rate.




























High Capacity Sand Dredger With Deep Water Dredging Ability Solid Capacity 600-700m3/H

High Capacity Sand Dredger With Deep Water Dredging Ability Solid Capacity 600-700m3/H

High Capacity Sand Dredger With Deep Water Dredging Ability Solid Capacity 600-700m3/H


Advantage:


Novel design, High efficient, large output, long discharge distance.
High quality wear resistance and long serve life sand pump.
Pumping depth reaches up to 20-30m underwater.
Dredge hull consists of multiple pontoons connected by proven coupling system.
Highly efficient fuel consumption and minimum overall operational costs.
Control box and instrument are mounted in ergonomic dash board.
Low investment and good operating performance.
Simple and fast assembly and disassembly, easy to operate.
